Product Overview
Sunny Sky A2212 980KV Brushless Motors (Counterclockwise)
The Sunny Sky A2212 980KV Brushless Motor (Counterclockwise) is engineered to deliver a perfect combination of power, efficiency, and reliability for RC aircraft applications. With a 980KV rating, this motor offers an ideal balance between speed and torque, making it suitable for both RC planes and multi-rotor drones.
Its counterclockwise (CCW) rotation ensures proper synchronization in drone configurations, while the integrated cooling fins effectively dissipate heat, allowing consistent performance during extended flight sessions.
Built using high-quality materials, the motor is designed for durability and long-term use even in demanding conditions. Additionally, its standard mounting compatibility makes installation quick and hassle-free, making it a dependable choice for hobbyists and professionals looking to enhance their flying experience.
Features:
High Performance: The Sunny Sky A2212 980KV Brushless Motor - CCW delivers exceptional power and performance to your RC aircraft.
Reliable Construction: This engine is built with high-quality materials, ensuring durability and longevity even under heavy use.
980KV Rating: The motor's 980KV rating provides an optimal blend of thrust and efficiency, making it appropriate for a wide range of aircraft types.
Counterclockwise (CCW) Rotation: Designed for counterclockwise rotation, making it simple to incorporate into your RC system.
Enhanced Cooling: The motor has cooling fins that efficiently dissipate heat over extended flights.
Easy Installation: The motor's user-friendly design makes installation simple and compatible with typical mounting patterns.
Technical Specifications
| Parameter | Value |
|---|---|
| Motor KV (RPM/V) | 980 KV |
| Motor Type | Brushless Motor |
| Stator Thickness | 12 mm |
| Stator Diameter | 22 mm |
| No. of Stator Arms | 12 |
| No. of Stator Poles | 14 |
| No-Load Current (A/10V) | 0.7 A / 10V |
| Internal Resistance | 123 mΩ |
| Continuous Current | 20A (30s) |
| Max. Power | 330 W |
| Motor Weight | 56 g |
| Outer Diameter | 27.5 mm |
| Motor Body Length | 40 mm |
| Required ESC | 20 A |
| Recommended Propeller | 9450 |
| GTIN | 7501768335838 |
Use Cases
- 980KV brushless motor designed for optimal balance of thrust and efficiency
- Counter Clockwise (CCW) rotation for proper multi-rotor and RC aircraft setup
- Ideal for RC planes, quadcopters, and drone applications
- Built-in cooling fins for efficient heat dissipation during long flights
