ACS71020 Hall-effect Power Sensing and Overcurrent Detection Breakout -7Semi The ACS71020 Hall-effect Power Sensing and Overcurrent Detection Breakout by 7Semi offers a precision, isolated power monitoring solution designed for demanding industrial and high-power environments. Featuring integrated 16-bit ADCs, it delivers highly accurate real-time voltage and current measurements with a current sensing range of up to 90A. The module ensures safe operation through reinforced electrical isolation rated at 517 VRMS, eliminating the need for extra isolation components. With flexible communication options via I2C and SPI, it easily integrates with embedded and microcontroller systems. Enhanced with temperature compensation, offset correction, and voltage monitoring capabilities, the breakout supports comprehensive power analysis by providing key metrics such as active, reactive, and apparent power, along with RMS and instantaneous measurements, making it ideal for precise power system management and overcurrent fault detection. Features: Wide Current Sensing Range: Measures currents from 0 to 90A and is ideal for both low and high-power systems. Dual Communication Interface: A seamless connection via I2C or SPI allows for maximum design flexibility. High-precision 16-bit ADCs: Provide accurate voltage and current measurements for trustworthy power data. Advanced Power Analysis: Determines active, reactive, and perceived power, as well as power factor. Electrical Isolation: Reinforced up to 517 VRMS, removing the need for two isolated supplies. Fault Detection Features: Include overcurrent fault output pins and customizable voltage threshold notifications. Temperature Resilience: Can operate in a wide temperature range, making it suited for severe industrial environments. Zero Crossing Detection: The dedicated pin for voltage zero crossing improves phase control applications. Hall-Effect Sensing: Provides common-mode stray field rejection for enhanced signal integrity. Data Transmission Data transfer over I2C consists of numerous phases, as indicated in the sequence below. Start Condition: Defined by a negative edge on the SDA line, initiated by the Master while the SCL is high. Address Cycle: A 7-bit slave address plus one bit to indicate write (0) or read (1), followed by an acknowledge bit. Data Cycles: Reading or writing eight bits of data, followed by an acknowledgement bit. This cycle can be repeated to transport numerous bytes of data. The register address could be the first data byte received during a write. Stop Condition: A positive edge on the SDA line with SCL high.

BME680 Humidity, Pressure, Temperature and Gas Sensor Probe MRS Type -7Semi The BME680 Humidity, Pressure, Temperature and Gas Sensor Probe MRS Type - 7Semi is a robust, high-performance environmental monitoring solution built for demanding applications. Encased in a corrosion-resistant metal housing with a breathable membrane, it incorporates Bosch Sensortec’s BME680 digital 4-in-1 sensor to deliver highly accurate measurements of temperature, humidity, atmospheric pressure, and volatile organic compounds (VOCs). Designed for durability, the sensor excels in challenging environments with high dust, chemical exposure, or extreme temperatures. Its 1-meter cable and I2C interface ensure seamless integration with a wide range of systems operating on 1.7V to 3.6V. Whether deployed in HVAC systems, smart agriculture, industrial automation, or medical setups, the 7Semi BME680 provides stable, long-term data with minimal maintenance, making it a reliable choice for precision environmental sensing. Features: All-In-One Environmental Sensor: Temperature, humidity, barometric pressure, and gas levels (VOCs) are all accurately measured in one small instrument. Durable stainless steel metal casing: The breathable and corrosion-resistant metal shell provides long-lasting protection against harsh circumstances such as dust, humidity, high pressure, and explosive settings. Advanced Gas Detection: Detects a wide spectrum of volatile organic chemicals, which is useful for monitoring indoor air quality and assessing human health. Wide Operating Range: Pressure: 300-1100 hPa, Humidity: 0-100%, Temperature: -40°C to +85°C, making it appropriate for both indoor and outdoor use. I2C Digital Interface: Fully calibrated digital output enables simple integration with microcontrollers and embedded systems. Robust construction for harsh environments: Ideal for usage in vacuum chambers, pipelines, weather stations, soil monitoring systems, humidifiers, and explosive zones. The Mini Round Shell Connector with One-Meter Cable: Features a plug-and-play design and a 4-wire connection, making it ideal for deployment in tight spaces. High filtration efficiency: The stainless steel porous housing with specific pore diameters (5 to 120 microns) provides excellent dust interception and gas permeability. Low power consumption: Suitable for battery-powered and portable applications that demand energy efficiency. Exceptional stability and longevity: Long-term operational stability is supported by Bosch's established sensor technology.

7Semi EC200G-CN LTE Cat 1 4G GNSS Industrial Modem The 7Semi EC200G-CN LTE Cat 1 4G GNSS Mini Industrial Modem is designed for applications where reliable connectivity and accurate positioning matter the most. Built around the Quectel EC200G-CN module, it brings together stable LTE Cat 1 communication, multi-GNSS support, and flexible interfacing in a compact industrial-ready form. With USB-C and UART interfaces, it integrates seamlessly with embedded systems, PCs, industrial controllers, and IoT gateways, making it ideal for real-time data acquisition and cloud-based applications. Engineered for field-grade performance, this modem includes a nano-SIM slot, external wide-range 5–26 V power input, and a high-efficiency FPC antenna with IPEX for strong and stable signal reception. Whether you’re building smart metering systems, industrial automation setups, or vehicle tracking solutions, this LTE Cat 1 GNSS modem ensures dependable communication, consistent GPS accuracy, and effortless deployment across diverse IoT environments. Features: LTE Cat 1 connectivity powered by the Quectel EC200G-CN module for stable and efficient cellular communication. Dual communication interfaces with USB-C and UART, allowing flexible integration with microcontrollers, edge devices, and computers. Wide input voltage support (5–26 V) for reliable operation in industrial and field deployments. Multi-GNSS system support including GPS, GLONASS, BeiDou, Galileo, and QZSS for precise and continuous location tracking. High-efficiency FPC antenna with IPEX (u.FL) connector ensures strong cellular and GNSS signal reception. Nano-SIM slot enabling immediate network access for IoT, telemetry, and monitoring systems. Compact, rugged, and installation-friendly design suitable for demanding environments and professional applications. Pinout Diagram:

EC200U 4G LTE GNSS Industrial Modem with USB C and 5–26V Input Range - 7Semi For IoT, M2M, and industrial applications, 7Semi's EC200U 4G LTE GNSS Industrial Modem is a small and powerful device. The Quectel EC200U-CN Cat 1 LTE module powers this 4G LTE modem, which ensures precise real-time positioning by supporting a variety of international GNSS systems such as GPS, GLONASS, BeiDou, Galileo, and QZSS. This industrial modem is perfect for embedded and remote systems because it supports two interfaces, USB-C and UART, and provides flexible power options via 5V USB or 5–26V external input. Even in difficult situations, dependable wireless data transfer is ensured by its integrated nano SIM support and multi-band connectivity (LTE-FDD, LTE-TDD, and GSM). This Cat 1 LTE GNSS modem, which has a high-gain FPC antenna (700–2700 MHz), provides reliable tracking and communication through strong signal performance. Because of its small size and adhesive mounting, it can be integrated into smart meters, asset tracking devices, transportation systems, IoT devices, and industrial automation setups. EC200U 4G LTE GNSS Module Dimensions

EC200U 4G LTE GNSS Industrial Modem with USB C and 5–26V Input Range - 7Semi For IoT, M2M, and industrial applications, 7Semi's EC200U 4G LTE GNSS Industrial Modem is a small and powerful device. The Quectel EC200U-CN Cat 1 LTE module powers this 4G LTE modem, which ensures precise real-time positioning by supporting a variety of international GNSS systems such as GPS, GLONASS, BeiDou, Galileo, and QZSS. This industrial modem is perfect for embedded and remote systems because it supports two interfaces, USB-C and UART, and provides flexible power options via 5V USB or 5–26V external input. Even in difficult situations, dependable wireless data transfer is ensured by its integrated nano SIM support and multi-band connectivity (LTE-FDD, LTE-TDD, and GSM). This Cat 1 LTE GNSS modem, which has a high-gain FPC antenna (700–2700 MHz), provides reliable tracking and communication through strong signal performance. Because of its small size and adhesive mounting, it can be integrated into smart meters, asset tracking devices, transportation systems, IoT devices, and industrial automation setups. EC200U 4G LTE GNSS Module Dimensions

7Semi PT100 RTD 3-Wire Temperature Sensor Probe The 7Semi PT100 RTD Temperature Sensor Probe is built for engineers and industrial users who need dependable, high-accuracy temperature monitoring across a wide operating range. Using a premium JUMO PCA 1.2003.1EG platinum-chip element, this probe follows the IEC 60751:2008 Class F0.15 (Class A) standard, ensuring precise and stable readings from -70°C to +300°C. Its platinum resistance design offers exceptional repeatability with minimal drift, making it a reliable choice for long-term process monitoring and industrial automation systems. Designed with a durable 2-inch stainless steel probe and a 3-metre insulated 3-wire cable, this PT100 sensor is ideal for harsh, wet, or corrosive environments. Whether used in chemical plants, HVAC systems, laboratory setups, industrial machinery, or temperature-controlled processing units, it delivers consistently accurate performance. This combination of precision, durability, and affordability makes it a smart upgrade for anyone looking for a high-accuracy industrial temperature sensor. Features: Designed with a wide operating range from -70°C to +300°C, making it suitable for demanding industrial and laboratory applications. Built with a JUMO PCA platinum-chip element that meets IEC 60751:2008 Class F0.15 (Class A) standards for high accuracy and stability. Equipped with a 2-inch stainless steel probe, offering long-lasting durability even in harsh or corrosive conditions. Comes with a 3-metre insulated 3-wire cable, allowing easy installation in remote or hard-to-reach areas. Utilises platinum resistance technology for excellent repeatability, low drift, and consistent output over time. Features a waterproof design, enabling reliable operation in moisture-rich environments. Offers a cost-effective, high-reliability solution suitable for automation systems, industrial processes, and precision monitoring tasks.

7SEMI PT100 RTD Temperature Sensor Probe 2-wire 1m -70~300C The 7SEMI PT100 RTD Temperature Sensor Probe 2-wire 1 m (-70 ~ 300°C) (ES-13519) is a reliable temperature sensor designed to deliver accurate and stable readings across a wide temperature range. It uses a platinum PT100 RTD element, which is well known for precision and long-term consistency, making it suitable for both learning and professional applications. The sensor comes with a 1-meter cable and a sturdy stainless-steel probe that can handle demanding environments. Its simple 2-wire design makes it easy to connect with temperature controllers, data loggers, and microcontroller-based systems. Whether you’re working on industrial monitoring, laboratory experiments, or electronics projects, this PT100 probe offers a good balance of accuracy, durability, and ease of use. Features: Uses a PT100 platinum RTD element for accurate and stable temperature measurement Wide operating temperature range from -70°C to 300°C 2-wire configuration for simple and reliable connectivity Stainless steel probe for durability and long service life Comes with a 1-meter insulated cable for flexible installation Suitable for industrial, laboratory, and electronics projects Provides consistent readings over time with minimal drift

RS485 Industrial Grade Temperature & Humidity Sensor Probe -7Semi The RS485 Industrial Grade Temperature & Humidity Sensor Probe from 7Semi is a robust and high-precision solution designed for demanding industrial applications. Featuring the advanced SHT45 sensor, it delivers accurate and stable environmental data through a reliable RS485 Modbus RTU interface, making it ideal for integration into SCADA systems, PLCs, HVAC setups, and environmental monitoring platforms. Its durable aluminum alloy housing is waterproof, breathable, and dust-proof, ensuring consistent performance even in harsh conditions. With a wide temperature range of -40°C to 125°C and 0% to 100% RH humidity measurement, this sensor is built for extreme environments. The included 1-meter cable allows for convenient installation in remote or difficult-to-access locations. Features: High-Accuracy Sensing: Built on the sophisticated SHT45 sensor for precise temperature and humidity readings. RS485 Modbus RTU Output: Enables straightforward interaction with industrial control systems and data recorders. Wide Operating Range: Measures temperature from -40°C to 125°C, humidity from 0% to 100% RH. Durable Construction: Aluminum alloy casing with waterproof, dust-proof, and breathable design Long-Term Stability: Optimized for continuous usage in difficult conditions without losing accuracy. Flexible Power Supply: Supports 9-60V DC input, compatible with many industrial configurations. Configurable Communication: DIP switch for Modbus address and baud rate change. 2-Meter Cable Length: Allows for flexible mounting and installation in various locations.

Official Arduino Portenta H7 Development Board The Official Arduino Portenta H7 Development Board is a powerful and versatile board designed to execute high-level code alongside real-time operations. Featuring a dual-core architecture, it allows two processors to run tasks in parallel — for instance, executing Arduino-compiled code on one core and MicroPython on the other, with seamless inter-core communication. This makes the Portenta H7 ideal for complex applications requiring multitasking and modularity. It functions both as a traditional embedded microcontroller and as the main processor of an embedded computer when paired with the Portenta Carrier board, which transforms it into an eNUC form factor and provides access to all physical interfaces. Designed for advanced edge computing, the Portenta H7 development board is capable of running TensorFlow Lite processes, enabling on-the-fly computer vision and AI tasks on one core while managing low-level operations like motor control or UI on the other — all in real time. Applications: High-end industrial machinery Laboratory equipment Computer vision PLCs Industry-ready user interfaces Robotics controller Mission-critical devices Features: Designed for High-End Industrial Applications: Suitable for advanced automation systems and precision machinery. Optimized for Laboratory Equipment: Ensures reliability and accuracy in research and testing environments. Supports Computer Vision Tasks: Capable of running real-time image processing with TensorFlow Lite. PLC Integration Ready: Can be used as a programmable logic controller in industrial settings. Industry-Grade User Interface Support: Handles sophisticated UI operations for industrial and commercial systems. Powerful Robotics Controller: Ideal for controlling multi-axis robots and robotic arms with real-time responsiveness. Mission-Critical Device Capabilities: Built for systems where reliability and uptime are crucial. Can Function as a Dedicated Stationary Computer: When combined with the Portenta Carrier board, it becomes a compact embedded computer. Ultra-Fast Booting Time: Boots in milliseconds, enabling quick startup and minimal downtime. Arduino Portenta H7 Pinout Diagram:

Official Arduino Portenta X8 AI + Linux Industrial SOM (System on Module) The Official Arduino Portenta X8 is a high-performance, industrial-grade System on Module (SOM) designed for demanding edge computing applications. It comes preloaded with a Linux operating system and supports modular container-based software architecture, allowing device-independent application development. Featuring a unique combination of power and flexibility, the Arduino Portenta X8 integrates a total of nine processing cores, including a quad-core NXP i.MX 8M Mini Cortex-A53 running up to 1.8GHz, a Cortex-M4 at 400MHz, and a dual-core STMicroelectronics STM32H747 with Cortex-M7 and M4 MCUs. This architecture enables real-time operations through the Arduino environment while Linux handles complex, high-speed processing tasks. Built-in Wi-Fi and Bluetooth Low Energy connectivity further enhance the X8’s capabilities by enabling secure over-the-air (OTA) updates for both the OS and applications, making it ideal for industrial IoT and AI workloads at the edge. Applications: Connected edge computer for manufacturing Autonomous Guided Vehicles (AGV) Interactive full-HD secure kiosks and digital signage Office & home control systems Navigation and control for smart agriculture Behavioral analytics for offices and factories Features: Two-in-One Industrial Solution: Combines the power of a container-based Linux distribution with the flexibility of the Arduino ecosystem. High Computational Density: Packs 9 processing cores into a compact, space-efficient form factor. Advanced Multi-Processor Architecture: Enables efficient, power-optimized task distribution across cores. Language Flexibility: Supports popular programming languages including Python, Java, Ruby, and more. Dedicated Real-Time Core: Handles real-time I/O operations and fieldbus/control functions separately from high-level processing. Edge AI and Machine Learning Ready: Designed to run advanced AI algorithms and ML models directly at the edge. Secure Over-the-Air Updates: Supports OTA updates for both OS and applications with built-in wireless connectivity. Hardware-Level Security: Features a dedicated crypto chip for industrial-grade, hardware-based security. Expandable via Arduino Ecosystem: Seamlessly integrates with other official Arduino Portenta modules and accessories. Multi-Protocol Routing Capability: Capable of handling diverse protocols through a single, unified platform. Portenta Compatibility: Fully compatible with other products in the Arduino Portenta family for flexible development.
