N20 shaft motor 600 RPM - 12V
Delivery & Pickup Options
Order now and we'll have it ready for delivery by the next business day.
N20 shaft motor 600 RPM - 12V The N20-12V-600 RPM Micro Metal Gear Motor is a compact yet powerful motor with all-metal gears that are durable and resistant to wear and tear. It can serve as an excellent replacement for a rusty or damaged DC geared speed reduce motor on a machine. This motor is commonly used in a variety of applications such as boats, cars, electric bicycles, fans, and home appliances. The N20 Micro Gear 12V 600 RPM DC Motor (High Torque) is a lightweight motor with high torque and low RPM. Equipped with a gearbox assembly, it can significantly increase the torque of the motor. The motor's cross-section measures 10 × 12 mm, while the D-shaped gearbox output shaft is 9 mm long and 3 mm in diameter. Due to its compact size, this Micro Gear Motor is ideal for use in small-scale applications with limited space. It can be easily connected to wheels to drive heavy loads from one location to another. Features: This is a DC Mini Metal Gear Motor, ideal for making robots Lightweight, high torque and low RPM. Fine craftsmanship, durable, not easy to wear. With excellent stall characteristics, can climb hills easily. You can also easily mount a wheel on the motor’s output shaft.
- High-torque micro gear motor with all-metal construction
- Operates at 12V DC, 600 RPM no-load speed
- Compact size: 10 × 12 mm cross-section
- D-shaped shaft: 9 mm long, 3 mm diameter
- Compatible with Arduino, Raspberry Pi, and motor drivers
- Ideal for robotics, automation, and embedded systems
- Durable all-metal gearbox for long life
- High torque output with low RPM
- Lightweight and space-efficient design
- Excellent stall characteristics for load handling
- Easy integration with wheels and mechanical assemblies
| No Load Current (mA) | 0.06 A |
|---|---|
| Rated Torque(kg-cm) | 0.18 |
| Stall Current (A) | 0.75 |
| Rated Operating Voltage (VDC) | 12 |
| Operating Voltage (VDC) | 6 ~ 12 |
| Weight (gm) | 12 |
What is the voltage and RPM of the N20 motor?
The N20 motor operates at 12V DC and delivers 600 RPM with high torque output.
Can this motor be used with Arduino or Raspberry Pi?
Yes, the N20 motor is compatible with Arduino, Raspberry Pi, and other microcontrollers via motor driver modules.
What are the dimensions of the motor and shaft?
Motor cross-section: 10 × 12 mm. D-shaped output shaft: 9 mm long, 3 mm diameter.
Is this motor suitable for robotics and automation projects?
Yes, it's ideal for robotics, drones, conveyor systems, and small automation due to compact size and high torque.
To rate this product please login!
About N20 shaft motor 600 RPM - 12V by Iotcart
Shop high-torque N20 gear motor, 12V, 600 RPM. Compatible with Arduino, Raspberry Pi. Ideal for robotics & automation projects.
Categorised under: DC Motors› Gear Motors
