ELECROW 6 Axis CNC Controller for FluidNC
This CNC controller is built to manage a diverse range of machines. It supports up to 6 motors and various spindle and laser types. The setup is user-friendly, requiring no software compilation. All configuration, upgrades, and other settings can be managed through a web browser. Below are its key features.
Features
ESP32 Controller: Integrated with USB-C connectivity.
Motor Support: 6 motor connectors (5V signals), each with step, direction, and enable signals. Supports up to 6 axis or dual motors per axis.
Switch Inputs: 8 input ports for limits, probes, and control switches.
Spindle Compatibility: Supports RS485, 0-10V, PWM, relay, BESC, and laser spindles.
MOSFET Outputs: 2 x 3A MOSFETs for relays, solenoids, and valves.
Flexible Output: Unused 5V spindle outputs can be used for functions like coolant.
Storage: Micro SD card socket for G-code files.
Expansion: Module socket for GPIO extenders and pendant interfaces.
ESP32-based controller with USB-C and Wi-Fi connectivity
Supports up to 6 stepper motors with step/direction/enable signals
Web-based configuration via FluidNC—no compilation needed
8 digital inputs for limits, probes, and controls
Compatible with RS485, 0-10V, PWM, relay, BESC, and laser spindles
2 x 3A MOSFET outputs for relays and solenoids
Micro SD card slot for G-code storage and standalone operation
Expansion socket for GPIO and pendant interfaces
Web-based configuration and real-time control
Supports multi-axis CNC and laser systems
No software compilation required
Standalone operation with SD card
Expandable via GPIO and pendant modules
Feature
Specification
Controller
ESP32 with USB-C
Motor Connectors
6 (5V signals)
Motor Setup
Up to 6 axis or dual motors per axis
Signal Support
Step, direction, enable with LEDs
Switch Inputs
8 (limits, probes, control)
Spindle Support
RS485, 0-10V, PWM, Relay, BESC, Laser
MOSFET Outputs
2 x 3A for relays, solenoids, valves
5V Outputs
Repurposable (e.g., coolant)
LED Indicators
On most outputs
Storage
Micro SD card
Expansion
Module socket for GPIO extenders, pendant
Dimensions (LxWxH)
7cm x 9cm x 0.2cm
Weight
86gm
What firmware does the SES-P-2000 support?
The SES-P-2000 is pre-configured for FluidNC firmware and compatible with Arduino IDE for custom development.
How many motors can the controller drive simultaneously?
It supports up to 6 stepper motors with independent control signals, enabling 6-axis operation or dual motors per axis.
Can I use this controller without a computer?
Yes, with a micro SD card loaded with G-code, the controller can operate standalone via FluidNC.
Is it compatible with laser modules?
Yes, it supports PWM and TTL laser control, making it suitable for laser engraving and cutting applications.
