Radiolink R6DS 2.4GHz 6 Channel RC Receiver for Drones, Airplanes
Expected restock within 5-7 business days. We'll ship immediately once available.
For urgent inquiries, please contact us .
Delivery & Pickup Options
Expected to be in stock within 5-7 business days. We'll ship immediately once available.
Radiolink R6DS 2.4GHz 6 Channel RC Receiver for Drones, Airplanes The Radiolink R6DS RC Receiver is designed for reliable, high-performance remote control of drones, airplanes, and fixed-wing aircraft. Equipped with DSSS & FHSS protocols, it delivers exceptional anti-interference capability, ensuring stable and precise control even in challenging environments. This versatile 2.4GHz RC reciever supports PPM, SBUS, and PWM signal outputs, making it compatible with a wide range of Radiolink transmitters, including AT9, AT9S, AT9S Pro, AT10, and AT10II. Whether you are flying a drone or a fixed-wing aircraft, the R6DS provides seamless connectivity and accurate response for enhanced flight performance. For added safety, the reverse polarity protection circuit safeguards the drone receiver from damage if the power connections are mistakenly reversed, giving you peace of mind during installation. Compact, reliable, and easy to use, the Radiolink R6DS is an ideal choice for both hobbyists and professional RC pilots. Features Excellent Anti-Interference: Uses DSSS & FHSS pseudo-random algorithm for stable, interference-free control. 6/10 Channels Support: Compatible with PWM, PPM, and SBUS outputs; ideal for most aircraft. Ensure SYSTEM CH is set to 10CH when using AT10/AT10II. Fast Response: High-resolution ratio of 4096 with 0.5µs stability for low-latency, precise control. Easy Binding: One-second press of the bind button powers up and connects the receiver-no old bind plugs or complex radio settings needed. Anti-Polarity Protection: Safeguards the receiver from damage if the power is connected incorrectly.
- 6-channel 2.4GHz RC receiver with DSSS & FHSS technology
- Supports PWM, PPM, and SBUS signal outputs
- Compatible with Radiolink AT9, AT9S, AT10, and AT10II transmitters
- One-second binding via physical button—no bind plug required
- Reverse polarity protection for safe power connection
- High resolution: 4096 steps with 0.5µs signal stability
- Advanced anti-interference with DSSS & FHSS
- Fast response time for low-latency control
- Easy one-button binding process
- Reverse polarity protection circuit
- Compact and lightweight design
- Wide transmitter compatibility
| Channel | PWM: 6CH, SBUS & PPM: 10CH |
|---|---|
| Signal Output | SBUS / PPM / PWM |
| Model | Racing Drone / Quadcopter |
| Control Distance | More than 600m Air Spread |
| Spectrum | FHSS |
| Working Current | 38–45 mA (5V) |
| Power | 3~6V |
| RF Power | <10 dBm |
| Accuracy | 4096 |
| Size | 0.98 × 0.59 × 0.4 in |
| Weight | 3.5g |
Is the Radiolink R6DS compatible with AT10II transmitter?
Yes, the R6DS is fully compatible with Radiolink AT10 and AT10II transmitters. Set SYSTEM CH to 10CH mode for full functionality.
What signal outputs does the R6DS support?
The R6DS supports PWM, PPM, and SBUS outputs, making it versatile for various flight controllers and servos.
Does the R6DS have anti-interference features?
Yes, it uses DSSS and FHSS protocols with pseudo-random algorithms for stable, interference-free operation in noisy RF environments.
Can I use this receiver with drones and airplanes?
Absolutely. The R6DS is designed for drones, fixed-wing airplanes, and other RC aircraft requiring reliable 2.4GHz control.
