Laser Receiver Module

Laser Receiver Module LASER lights have many applications like in counting, time measurement, laser guidance systems etc. It is very vital to correctly read and perform the corresponding function given in your code as any misread or malfunction in system can lead to fatal errors and losses to company. To keep this error in check this Non- Modulator Tube LASER Receiver sensor module is there to help you read the incoming laser signals accurately. It gives output of laser receiver in digital format and output pin is high when LASER is detected and low when LASER is not detected. This module works on 5V Voltage input and due to its small size you can use it in portable devices and industrial equipment. This Laser Receiver Sensor Module Laser output High Level is a sensor for Raspberry Pi and Arduino to receive the laser output and decode it digital data. At Input, the module Receives a laser signal when output high level; Does not receive a laser signal when output low level. On detecting a laser signal, output goes at a high level (5V) until the laser signal is there. Circuit diagram As you can see the setup consists only one amber LED and its current limiter 10K resistor connected across the output of the module (OUT & VCC). Features: PCB Color: Green Output high level when receiving the laser signal Output low level when not receiving laser signal. Application: Electronic Circuits
