Mornsun LM60-12A15 AC/DC 60W Enclosed Switching Power Supply
Mornsun LM60-12A15 AC/DC 60W Enclosed Switching Power Supply The LM60-12A15 series is a dual output, non-isolation, enclosed AC-DC switching power supply from Mornsun. It features a universal AC input, accepts DC input voltage, is cost-effective, highly efficient, reliable, and has double or reinforced insulation. The converters offer excellent EMC performance and meet IEC/EN61000-4, IEC/UL/EN62368, and GB4943 standards. They are not only used in the laser galvanometer industry, but also in current sensors, motors, and other fields. Features Universal AC input: The power supply can be used with any AC input voltage between 90 and 264 volts. DC input voltage: The power supply can also be used with a DC input voltage between 240 and 370 volts. Ultra low standby power consumption: The power supply consumes less than 0.75 watts of power when it is in standby mode. Wide operating temperature range: The power supply can operate in temperatures ranging from -30 to 70 degrees Celsius. LED indicator for power on: The power supply has a LED indicator that shows when it is turned on. Output short circuit, over-current, over-voltage, and over-temperature protection: The power supply has built-in protection against short circuits, over-current, over-voltage, and over-temperature conditions. Built-in DC fan: The power supply has a built-in DC fan that helps to keep the power supply cool. Operating up to 5000 meters altitude: The power supply can operate up to 5000 meters above sea level. The LM60-12A15 series is a versatile and reliable power supply that can be used in a variety of applications. It is a good choice for applications that require a universal AC input, low standby power consumption, a wide operating temperature range, and built-in protection against short circuits, over-current, over-voltage, and over-temperature conditions. Note: Unless otherwise specified, parameters in this datasheet were measured under the conditions of Ta=25℃, humidity<75%RH with nominal input voltage and rated output load The room temperature derating of 5℃/1000m is needed for operating altitude greater than 2000m All index testing methods in this datasheet are based on our company's corporate standards In order to improve the efficiency at high input voltage, there will be audible noise generated, but it does not affect product performance and reliability The out case needs to be connected to the earth ( )of system when the terminal equipment in operating The output voltage can be adjusted by the ADJ, clockwise to increase Our products shall be classified according to ISO14001 and related environmental laws and regulations and shall be handled by qualified units The power supply is considered a component which will be installed into the final equipment. All EMC tests should be confirmed with the final equipment Package Includes: 1 x Mornsun LM60-12A15 AC/DC 60W Enclosed Switching Power Supply Specifications: Type Enclosed Type Dual Output Output Power 60W Series LM60-12A Part Number LM60-12A15 Mount Enclosed IP Level Non-Waterproof Output Voltage 15V, -15V Output Current 2A, 2A
- Universal input voltage of 165 - 264VAC or 180 - 370VDC
- Operating ambient temperature range of -30℃ to +70℃
- Low standby power consumption and high efficiency
- Output short circuit, over-current, and over-voltage protection
- High I/O isolation test voltage up to 3000VAC
- Operating altitude up to 5000m
- Design compliant with IEC/UL62368-1, EN60335-1, EN61558-1, and GB4943.1
