Arduino Uno R3 Original

Arduino UNO R3 Original The Arduino Uno R3 is a microcontroller board based on the ATmega328P chip . This board has 14 digital I/O pins (6 support PWM), 6 analog inputs , a 16 MHz crystal resonator , a USB connector, a power jack, an ICSP header, and a reset button. You may quickly charge it with a USB cable, adapter, or battery. The Uno R3 is designed for both students and enthusiasts and makes electronics and coding accessible without requiring extensive technical knowledge. This Arduino UNO microcontroller board can be programmed using the Arduino IDE , which allows users to build sketches (code) that control the board. Even if something goes wrong, simply change the chip and restart. "Uno" means "one" in Italian, and it marks the release of the Arduino IDE 1.0. It became the standard and reference model for subsequent Arduino boards. Common uses of the Arduino Uno board include home automation, industrial control, and DIY electronics projects. It can also interface with other Arduino boards or Raspberry Pi, making it a flexible choice for creators and students. Check out the original Arduino UNO R4 WiFi ! Read our blog IR sensor Arduino code for interfacing IR sensor module with Arduino. Browse the best collection of original Arduino products. Key Features ATmega328P microcontroller ensures reliable and efficient performance Includes 14 digital input/output pins, with 6 supporting PWM output Features 6 analog input pins for reading sensor or variable data Equipped with a 16 MHz ceramic resonator for stable timing Offers 32 KB flash memory (0.5 KB used by bootloader), 2 KB SRAM, and 1 KB EEPROM Can be powered via USB, DC adapter (7–12V recommended), or battery Integrated USB-to-serial communication using ATmega16U2 for easy programming Built-in resettable polyfuse provides protection against USB overcurrent Supports automatic reset for quick and easy code uploads Includes an onboard LED on digital pin 13 for basic testing Supports serial (UART), SPI, and I2C communication protocols Compatible with a wide range of Arduino shields for project expansion Easy to use, making it perfect for beginners and DIY electronics enthusiasts Arduino UNO Pin Diagram The power pins are as follows: Pin Description Vin The input voltage to the Arduino board when using an external power source (7–12V). You can supply voltage through this pin, or access it if supplying voltage via the DC power jack. 5V Outputs a regulated 5V from the onboard regulator. Power can come from the USB, DC jack, or Vin pin. Do not supply power to this pin directly , as it bypasses the regulator. 3.3V Outputs 3.3 volts generated by the onboard regulator. Maximum current draw is 50 mA. GND Ground pins used to complete the circuit. Multiple GND pins are available. IOREF Provides the voltage reference at which the microcontroller operates. Shields can use this pin to adapt to the board’s voltage (5V or 3.3V). Explore a wide range of Original Arduino Boards on Iotcart. Why Choose Arduino Uno R3? Beginner-friendly: Easy to use with a simple IDE and beginner-level coding language. Strong community support: Large global community, tutorials, and troubleshooting help available. Wide ecosystem: Compatible with various shields, sensors, and components. Affordable: Budget-friendly option for students, hobbyists, and beginners. Highly versatile: Ideal for projects from basic LED control to complex IoT systems. Reliable starting point: Best entry-level board before exploring advanced Arduino models. Open-source platform: Hardware and software are fully open-source, allowing customization and innovation. Stable performance: Offers consistent and reliable operation for long-term learning and prototyping. Arduino Nano vs Uno Comparison Table Feature Arduino UNO R3 (Original) Arduino Nano (Original) Price (Iotcart) ?1,860 ?1,798 VIEW Microcontroller ATmega328P ATmega328P Operating Voltage 5V 5V Input Voltage 7-12V 7-12V Digital I/O Pins 14 (6 PWM) 14 (6 PWM) Analog Input Pins 6 8 Clock Speed 16 MHz 16 MHz Flash Memory 32 KB (0.5 KB used by bootloader) 32 KB (0.5 KB used by bootloader) SRAM 2 KB 2 KB EEPROM 1 KB 1 KB USB Interface Standard USB Type-B Mini USB Size Larger (approx. 68.6mm x 53.4mm) Compact (approx. 45mm x 18mm) Best for Beginners, shields, projects needing standard size Compact projects, breadboard-friendly applications Wireless Capability Needs external module (e.g., ESP8266, HC-05) Needs external module (e.g., ESP8266, HC-05) Expandable with Shields Yes, compatible with multiple shields Limited due to size constraints Project Ideas with Arduino Uno R3 LED Blinking Project Temperature & Humidity Monitor Smart Home Automation Obstacle-Avoiding Robot Automatic Plant Watering System Digital Thermometer Motion Detector Alarm IoT Weather Station RFID Door Lock System Line Follower Robot Smart Parking System Bluetooth-Controlled Car Light Follower Robot Heart Rate Monitor Home Security System Know How to Install Arduino IDE on Windows, Mac & Linux - Click HERE !
