Seeed Studio XIAO nRF52840 Module & Wio-SX1262 Kit for Meshtastic The Seeed Studio XIAO nRF52840 Module & Wio-SX1262 Kit is a powerful combination designed for modern IoT and wireless networking projects. Featuring the nRF52840 module and SX1262 transceiver, it supports BLE 5.0 and LoRa (862-930MHz) for reliable, long-range communication with low power consumption. This versatile kit is perfect for applications such as Meshtastic, environmental monitoring, sensor networks, asset tracking, and educational or innovative experiments. It's compact design and robust features make it an ideal solution for developers, makers, and students exploring connected device projects. Features: Versatile Microcontroller: Incorporate the Nordic nRF52840 chip with FPU, working up to 64 MHz, mounted several development ports, supported by Arduino, CircuitPython, and Micropython. Long-range: LoRa on the Semtech SX1262 supports the 868/915 MHz bands, providing powerful performance. Dual-core communication: It supports Bluetooth and LoRa dual modes, allowing for cross-domain interconnection. The integrated antenna is 8mm × 22mm × 23mm. Applications: Meshtastic Node&Router: An extremely compact node that may be used as a portable device or a stationary router to expand the Meshtastic network. LoRa/LoRaWAN Sensor: A little LoRaWAN sensor, excellent for those new to LoRa/LoRaWAN. When paired with a GPS module (such as the XIAO L76K), it can be used to track the movement of logistical vehicles, livestock, and important equipment. LoRa's long-distance coverage (2-5 km in urban areas and more than 10 km in suburban areas) can help to lower the cost of base station placement. Hardware Overview of XIAO nRF52840 Module: Pinout Diagram: Hardware Overview of Wio-SX1262: Pinout Diagram:

Seeed Studio Seeeduino XIAO SAMD21 Arduino Compatible Board The Seeeduino XIAO SAMD21 is a compact yet powerful Arduino-compatible board built on the Microchip SAMD21G18 MCU. As the flagship of the Seeeduino XIAO series, this tiny board delivers professional-grade performance in a minimalist, SMD-designed form factor, making it perfect for space-constrained projects. It offers seamless compatibility with Arduino IDE, MicroPython, and PlatformIO, allowing flexible development for a wide range of applications. With extensive tutorials and learning resources, the Seeeduino XIAO SAMD21 is an excellent choice for beginners and hobbyists eager to explore open-source electronics. Features: Ultra-compact Seeeduino XIAO design Powered by SAMD21G18 MCU Arduino IDE, MicroPython & PlatformIO compatible Thumb-sized SMD package for space-saving projects Beginner-friendly with tutorials and learning resources Applications: Learning and Education (Arduino, MicroPython, Basic electronics, and prototyping) Wearable devices include health monitoring, interactive apparel, and tiny fitness trackers. IoT and sensor projects include environmental monitoring, data collection devices, smart home sensors, and small automation systems. Space-Constrained Mini Arduino Projects Rapid prototyping (fast proof-of-concept constructions, hardware testing, product prototypes, embedded system development) HID devices (do-it-yourself keyboard, USB to multi-channel TTL/USB host mode, Seeeduino XIAO SAMD21 Pinout Diagram

Seeeduino XIAO compatible with Arduino Seeeduino XIAO is the smallest Arduino compatible board in Seeeduino Family. It is an Arduino microcontroller that is embedded with the SAMD21 microchip. The interfaces of Seeeduino XIAO is rich enough in such a tiny Dev. Seeeduino XIAO is integrated with the powerful CPU-ARM® Cortex®-M0+(SAMD21G18) which is a low-power Arduino microcontroller. On the other hand, this little board has good performance in processing but needs less power. As a matter of fact, it is designed in a tiny size and can be used for Arduino wearable devices and small projects. Applications of Seeeduino XIAO: Wearable devices Rapid prototyping (directly attached to the expanded PCB as a minimal system) Perfect for all the projects need mini Arduino DIY keyboard USB development (USB to multi-channel TTL/USB host mode, etc.) A scenario where you need to read multiple mock values The Digital to Analog Converter output

LED Driver Board for XIAO Supports 5V and 12V LED Strips -Seeed Studio The LED Driver Board for XIAO by Seeed Studio is a versatile and compact solution designed for driving 5V and 12V LED strips, including popular addressable RGB LEDs like NeoPixel WS2812, WS2813, and WS2815. This LED driver board seamlessly integrates with all XIAO boards, providing smart lighting control and automation when paired with XIAO ESP32 Series using WLED and Home Assistant. It offers flexible power supply options, making it ideal for a wide range of lighting projects. Additionally, the board comes with comprehensive protection features, ensuring safe and reliable operation in home automation and creative lighting setups. Features: Wide LED Compatibility: The driver is versatile and can support both 5V/3A and 12V/2A LED strips. It also has integrated power regulation. Compatible with single-color and addressable RGB LEDs, including NeoPixel WS2811, WS2812(B), WS2813, WS2815, SK6812, and other 1-wire protocol LEDs, giving a wide range of lighting options. XIAO Compatibility for Smart Control: Designed to fit all Seeed Studio XIAO boards. When linked with the XIAO ESP32 Series (ESP32-C3/S3/C6), unlock smart features via WLED app support - Control colors, effects, brightness, and create creative animations (XIAO ESP32C3 comes strongly recommended). Home Assistant connection with ESP Home enables remote control, automation, and smart home scenarios. Grove Ecosystem Compatibility: The onboard Grove interface is compatible with over 400 Seeed Studio modules, such as infrared sensors, temperature sensors, accelerometers, and others, allowing you to easily improve lighting interactivity with the surroundings and motion for smarter, more personalized effects. Flexible Power Input: Supports 12V/2A power via a normal DC adapter (EU/US plugs) or direct DC wiring, with a universal 5.5mm x 2.1mm DC Barrel Jack connector. Suitable for temporary and permanent installations. Compact form factor: The space-efficient design enables for inconspicuous installation alongside LED strips or in tight places, making it appropriate for a variety of lighting applications while preserving full functioning. Comprehensive Protection: Overcurrent, overvoltage, overtemperature, and short-circuit protection are integrated to ensure reliable operation and component longevity. Hardware Overview: Applications: Home Lighting & Decoration: RGB strip lights, wall lights, and holiday decorations Educational and Science Experiments: Coding and Microcontroller Education, LED Light Design, Physical Data Visualization Gaming and interactive installations: PC case illumination, around-screen LED effects, interactive LED floor or wall. DIY Projects and Fun Uses: LED name boards, LED clocks, DJ disco lights, RGB mood lighting.

Seeed Studio XIAO ESP32-S3 Development Board Supports Wi-Fi & Bluetooth 5.0 The Seeed Studio XIAO ESP32-S3 Development Board is a compact and powerful ESP32 development board designed for IoT, smart home, wearable devices, and robotics projects. Powered by a 240MHz Xtensa 32-bit LX7 dual-core processor, it supports both Wi-Fi and Bluetooth 5.0 for seamless wireless communication. With its 2.4GHz rod antenna, reliable connectivity is ensured even in demanding environments. The board also features an ultra-low-power deep sleep mode, consuming as little as 14μA, making it perfect for battery-powered applications. Additionally, it includes lithium battery charging management, offering convenience for portable and energy-efficient projects. Features: Powerful MCU Board: Incorporates the ESP32S3 32-bit, dual-core, Xtensa processor working at up to 240MHz, mounted multiple development ports, Arduino and MicroPython support. Outstanding RF performance: Supports 2.4GHz WiFi and BLE 5.0 dual wireless communication, as well as 100m+ remote communication when linked with U. FL antenna. Elaborate Power Design: Lithium battery charge management capability, offering four power consumption models, including deep sleep mode with power consumption as low as 14μA. Thumb-sized Compact Design: 21 x 17.8mm, adopting the iconic XIAO form factor, appropriate for space-limited projects like wearable devices. Perfect for production: Breadboard-friendly and SMD design, with no components on the rear. Applications: Internet of Things Wearable devices Smart Homes Robotics Health monitoring Education Low-Power (LP) networking Rapid prototyping XIAO ESP32-S3 Development Board Pinout Diagram

Seeed Studio A603 Carrier Board for Jetson Orin™ NX/Orin™ Nano The Seeed Studio A603 Carrier Board for Jetson Orin™ NX/Orin™ Nano is a powerful and versatile extension board designed to maximize the performance of NVIDIA’s Jetson modules. Equipped with a GbE port, M.2 Key M for SSD storage, and M.2 Key E for WiFi/Bluetooth connectivity, it ensures seamless integration for data-intensive applications. With MIPI CSI and HDMI support, the carrier board enables high-quality video capture and display, making it ideal for AI vision projects. It also includes 4x USB ports, a built-in cooling fan, and RTC functionality, all powered by a flexible 9–20V input. Its compact and space-saving design allows easy integration into a wide range of edge computing and embedded AI solutions. Features: Compatible with Jetson Orin™ NX/Orin™ Nano modules High-speed Gigabit Ethernet (GbE) port M.2 Key M slot for SSD storage expansion M.2 Key E slot for WiFi/Bluetooth modules MIPI CSI and HDMI interfaces for video input/output 4x USB ports for peripheral connectivity Built-in cooling fan and RTC support Wide 9–20V DC power supply input Compact design for easy integration in edge computing Applications: Autonomous Mobile Robot (AMR) AI Video Analytics Machine Vision Generative AI Hardware Overview:

Seeed Studio CAN-BUS Shield V2 with High-Performance MCP2515 Controller & MCP2551 Transceiver The Seeed Studio CAN-BUS Shield V2 brings powerful CAN bus shield v2 functionality to your Arduino projects. Equipped with the high-performance MCP2515 CAN controller and MCP2551 transceiver, this CAN shield allows Arduino boards like the Arduino Uno to seamlessly communicate with CAN networks. It offers selectable OBD-II and CAN standard pinouts, along with a configurable CS pin for TF card slots and an INT pin for easy integration. Screw terminals make connecting CAN_H and CAN_L lines straightforward, enabling you to explore automotive hacking, CAN data monitoring, and other CAN-BUS applications effortlessly. Features: High-Performance ICs: stand-alone MCP2515 CAN-BUS controller and high-speed MCP2551 CAN transceiver Supports Industrial Standards: provides a 9-pin sub-D connector Medium Communication Speed: implements CAN V2.0B at up to 1 Mb/s Long Travel Distance: Standard (11-bit) and extended (29-bit) data and remote frames Two receive buffers with prioritized message storage What is CAN-BUS? CAN-BUS is a common industrial bus because of its long travel distance, medium communication speed, and high reliability. It is commonly found on modern machine tools and as an automotive diagnostic bus. CAN stands for Controller Area Network, it is used to allow microcontrollers and devices to communicate with each other within a vehicle without a host computer which allows for control and data acquisition. These devices are also called Electronic Control Units (ECU) and they enable communication between all parts of a vehicle. Today, you can find up to 70 ECUs in a modern car. CAN is a serial communication bus designed for industrial and automotive applications. For example, they are found in vehicles, farming equipment, industrial environments, etc. How does CAN-BUS work? The gasoline level, door sensors, odometer, and many other components of a car must communicate with one another in some way, and CAN BUS was employed to accomplish this. These CAN-compatible components, known as "nodes," are connected by a three-strand copper cable, with no central router to control data flow. Every node may hear the messages of all other nodes. Every node gets an ID, and the ones with the higher priority ID get to "talk" first while the others "listen". This ensures that no two nodes talk at the same time. The main advantage of CAN-BUS is the ability to simply connect components without having to worry about signal routing. CAN-BUS Shield V2 Hardware Overview:

SMD IC Adapters Set for Programmers By using the SMD IC adapter set, you can easily convert your SMD component into DIP format which makes the mounting process much easier. The set of 9 SMD IC adapter pieces are perfect for students, hobbyist & professionals who are trying to stream line their prototype-to-production process.

Seeed Studio XIAO nRF52840 Development Board Supports Bluetooth 5.0 The Seeed Studio XIAO nRF52840 Development Board is a powerful yet compact nRF52840 module designed by Nordic, bringing wireless capability to the XIAO family for the first time. This versatile nRF52840 board supports Bluetooth 5.0 and is optimized for low power consumption, making it an excellent choice for IoT, wearable devices, and Bluetooth-based applications. With its tiny size and robust performance, the Seeed Studio XIAO nRF52840 is the perfect microcontroller for developers looking to build efficient and reliable wireless solutions. Features: Versatile Microcontroller: Incorporate the Nordic nRF52840 chip with FPU, operating up to 64 MHz, mounted multiple development ports, supported by Arduino / CircuitPython /Micropython Wireless Capabilities: Implement Bluetooth 5.0, BLE functions with onboard antenna, also provide NFC connectivity Elaborate Power Design: Provide ultra-low power consumption as 5 μA in deep sleep mode while supporting lithium battery charge management Thumb-sized Design: 21 x 17.8mm, Seeed Studio XIAO series classic form-factor, suitable for wearable devices Perfect for Production: Breadboard-friendly & SMD design, no components on the back

TL866 - Universal IC Programmer The TL866II plus universal programmer is a well designed programmer of high density SMD technology, developed with an easy to use interface. TL866II plus USB programmer support 15000+ic spi flash and EEPROM 8051 MCU pic AVR gal. TL866ii plus programmer is the advanced version of TL866CS and TL866A programmer. The programming speed is much higher (up to double) of high-capacity memories as compared to TL866CS and TL866A programmers. It supports multiprogramming mode (up to four). Well-designed cheap professional programmer, Production of high-density SMD technology, a unified user interface, easy to use, fully functional, reliable program running of application software, ultra-small code -runs faster, supports bilingual (English and Chinese), it can automatically identify the operating system to install and run under win 2000/win XP/win 2003/win 2008/win vista /win7/win8/win10 (32biit/64bit). Key Features: The support simultaneously burns with 4 Programmers on each computer, the minimum volume, and the lowest power consumption, and does not feel any heat in the process. All chips do not need an external power supply, the low power consumption on its own ensures that the USB port can provide enough power. Best internal 40 pins over-voltage protection, the strongest VCC/app 4-level over current protection. The short circuit does not reset the pc. Wide range of chip 15000+ support, support for serial and parallel series 40/44/48pin large capacity flash. Unique serial icsp interface, supporting the serial download and high-speed parallel high voltage programming, test cmos4000 74/54 series integrated circuit, can be located in the gate circuit error, chip auto serial number is the most complete and practical. Original chip encryption operation on AVR microcontroller with internal RC Calibration byte, the decrypt software cannot be directly run on another same type of chip. Also check the HIPG854 Universal Programmer available on the Iotcart website, it is currently sold out. The universal programmer supports a wide range of devices, including ATMEL, AVR, PIC, EPROM, EEPROM, and many more ICs Features: Wide Compatibility: Supports programming for over 14,000 different devices, including EPROMs, EEPROMs, SPI FLASHs, DataFlash, and various microcontrollers. High-Speed Programming: Equipped with a high-performance MCU and USB interface, offering fast programming speeds. ICSP Port: Includes an In-Circuit Serial Programming (ICSP) port, allowing it to replace or eliminate the need for other programmers like Microchip PICkit or Atmel AVRISP. User-Friendly Interface: Designed with an easy-to-use interface, making it accessible for both beginners and professionals. Compact and Portable: Small and lightweight, making it easy to carry and use in various settings. Logic IC Testing: Can test the operation of logic ICs (CMOS and TTL), DRAMs, and SRAMs. Applications: Microcontroller Programming: Used for programming a wide range of microcontrollers from various manufacturers. EPROM and EEPROM Programming: Suitable for programming EPROMs and EEPROMs, which are used in many electronic devices. Flash Memory Programming: Can program SPI FLASH, DataFlash, and other types of flash memory. Logic IC Testing: Capable of testing the operation of logic ICs (CMOS and TTL), DRAMs, and SRAMs. In-Circuit Serial Programming (ICSP): Allows for in-circuit programming of microcontrollers, eliminating the need for separate programmers like Microchip PICkit or Atmel AVRISP. Development and Prototyping: Ideal for use in development and prototyping environments where multiple types of ICs need to be programmed.

Seeed Studio XIAO RP2350 Development Board Support Micropython / C, C++ The Seeed Studio XIAO RP2350 is a powerful and compact development board designed for a wide range of embedded applications. It integrates the Raspberry Pi RP2350 processor, featuring dual Arm Cortex-M33 cores running at 150 MHz and dual open-hardware RISC-V cores, offering enhanced performance, security, and encryption capabilities. With support for MicroPython, C, and C++, developers can easily create versatile, battery-powered projects such as smart controls, wearables, and DIY keyboards. Measuring only 21x17.8 mm, the board includes 19 multifunction GPIOs, an RGB LED, and a Battery Management System with ultra-low power consumption of just 27μA. Thanks to the XIAO ecosystem, the XIAO RP2350 seamlessly supports various add-ons, including displays, LED matrices, Grove modules, CAN Bus, Vision AI sensors, and mmWave sensors, making it a perfect choice for efficient and compact embedded system development. Features: Powerful MCU Board: The Raspberry Pi RP2350 processor has dual-core, dual-architecture capabilities, allowing developers to choose between two industry-standard Arm Cortex-M33 cores @ 150MHz with FPU and two open-hardware Hazard3 RISC-V cores. Enhanced Security Features: The built-in secure boot and encrypted bootloader provide application security. Software Support: Compatible with C/C++ and MicroPython, allowing for easy project development and prototyping. Rich Onboard Resources: Includes an RGB LED, 2MB Flash, 520kB SRAM, and 19 multifunction GPIOs (Analog, Digital, I²C, UART, SPI, PWM). Expanded 8 New IOs: Compared to prior XIAO MCUs, the addition of 8 IO pins on the back allows for more complicated applications. Efficient Power Design: In sleep mode, the device consumes only 27μA, making it suitable for battery power supply. Direct battery voltage measurement via internal I/O improves the battery management system (BMS). Compact, thumb-sized design: It is 21 x 17.8mm and uses Seeed Studio's iconic XIAO form factor, making it excellent for space-conscious applications. Production-friendly: Surface Mount Device (SMD) design features all components on the front and stamp holes on both sides, allowing for efficient mass manufacture. Hardware Overview: Pinout Diagram of XIAO RP2350 Front View Back View Applications: Smart Control Human Interface Devices (HID, such as mouse, DIY Mechanical Keyboard, joystick, console) Education Robotics Wearables

A203 V2 Carrier Board for NVIDIA Jetson Nano/Xavier NX/TX2 NX – Compact AI Development Board for Robotics & Embedded Systems - Seeed Studio The Jetson A203 V2 Carrier Board is an upgraded version of the A203, designed as a versatile and reliable NVIDIA Jetson Nano/Xavier NX/TX2 NX carrier board (A203 V2). It provides a wide range of peripheral interfaces, including support for Wi-Fi, Bluetooth, SSD storage, and more, making it highly adaptable for diverse industrial applications. From manufacturing and logistics to retail, agriculture, and beyond, this board enables developers to build end-to-end solutions with ease. With its compact size and lightweight design, the A203 V2 is an ideal compact AI development board for robotics, video analysis, and embedded systems. It’s well-suited for advanced robotics projects such as UAVs, unmanned boats, and submarines, offering seamless integration and stable performance. When paired with NVIDIA Jetson modules (sold separately), it empowers innovators, hobbyists, and professionals to accelerate development in robotics, computer vision, and edge AI. Features: NVIDIA Elite Partner Design – Built with reliability and compatibility in mind. 260-Pin Jetson Module Connector – Compatible with Jetson Xavier NX, Nano, and TX2 NX modules. Compact & Lightweight – Dimensions: 87mm × 52mm × 26mm; Weight: only 100g. Wide Operating Temperature – Stable performance from -25°C to 65°C for industrial environments. High-Speed Connectivity – 2 × USB 3.0 Type-A ports, 1 × USB 2.0 Micro-B connector, and USB 3.0 20-pin ZIF. Flexible Storage Expansion – Supports M.2 Key M SSD (2242) and MicroSD card. Reliable Networking – RJ-45 Gigabit Ethernet port (10/100/1000M). Multimedia Support – HDMI right-angle vertical connector and CSI camera interface. Rich I/O Interfaces – Includes UART, SPI, CAN, and GPIO for versatile peripheral integration. Stable Power Supply – Powered via 12V/5A DC jack for consistent performance. Application-Ready – Optimized for robotics, computer vision, video analysis, UAVs, and embedded AI solutions. Applications: Autonomous Mobile Robot (AMR) AI Video Analytics Machine Vision Generative AI A203 V2 Carrier Board Hardware Overview

Universal Programmer TOP2013 The TOP2013 is a universal programmer from Seeit. The TOP2013 is designed to work with components with up to 32 pin, from a range of manufacturers. These components include EPROMs, EEPROMs and FLASH memories. A full list of compatible devices can be found on the product datasheet. The Top2013 Universal programmer featuring an ARM Cortex 32 core and is housed in a compact package. It also offers low-power loss and overcurrent protection. Simply plug the TOP2013 into a PC via USB cable. The TOP2013 automatically starts programming once it detects a device has been inserted correctly into the ZIF40 socket. Features of TOP2013 Universal Programmer Model TOP2013 Universal Programmer Dimensions 11.5 x 9 x 2.5 cm Weight 250g Power < 2.5w (5v/500mA) Pins 40-pin Universal locking socket Operating System WINDOWS XP / WIN7 / WIN8 / WIN10 Transmission Speed 12MHz/s

TOP3000 Universal Programmer The Top3000 Universal Programmer is powered by a USB interface or a 5V power supply. This universal programmer is a Top3000 programmer which is small, lighweight, highly reliable, and consumes low power. The Top3000 Universal Programmer is highly compatible with notebooks and desktop computers. The TOP3000 programmer supports 2.5 ~ 6.5V device, Powered by your USB interface or the included 5V external power supply. With the fast transmission speed of 12MHz/s via the USB port, Auto detects the device's manufacturer and part number. It is easily compatible with Notebooks and desktop computers. The in-built connection inspection checks the connection for every pin in the unit. The current protection function protects both the programmer and connected devices, it has 48-pin self-lock sockets, a Compact programmer with a tough plastic casing

Seeed Studio XIAO ESP32-C6 Development Board Supports Wi-Fi 6, BLE 5.0, Zigbee & Thread The Seeed Studio XIAO ESP32-C6 development board is a powerful yet compact solution for modern IoT and smart home projects. Built on Espressif’s ESP32-C6 MCU, it supports advanced wireless connectivity including Wi-Fi 6, Bluetooth 5.0, Zigbee, and Thread, making it highly versatile for Matter-compliant applications. With its thumb-sized footprint and single-sided mount design, the board is ideal for space-constrained projects while still delivering strong performance. Integrated chip-level encryption ensures secure operation, while seamless compatibility with popular IoT cloud platforms enables developers to bring products to market faster. This ESP32 development board is a reliable choice for innovators looking to create next-generation connected devices. Features: Enhanced Connectivity: Includes 2.4GHz Wi-Fi 6 (802.11ax), Bluetooth 5 (LE), and IEEE 802.15.4 radio connectivity, allowing you to use the Thread and Zigbee protocols. Matter Native: Supports constructing Matter-compliant smart home projects through better connection and interoperability. Security Encrypted on Chip: Powered by ESP32-C6, it delivers increased encrypted-on-chip security to your smart home projects through secure boot, encryption, and Trusted Execution Environment (TEE). Outstanding radiofrequency performance: Has an on-board antenna with up to 80m of BLE/Wi-Fi range, while reserving an interface for external UFL antenna. Power Consumption: Offers four working modes, including deep sleep mode at 15 μA, and supports lithium battery charge management. Dual RISC-V Processors: Includes two 32-bit RISC-V processors, the high-performance CPU running up to 160 MHz, and the low-power processor clocking up to 20 MHz. Classic XIAO Designs: Retains the classic XIAO designs of the thumb-size form factor of 21 x 17.8mm and single-sided mount, making it ideal for space-limited projects such as wearables. Integration with popular cloud platforms: ESP Rain Maker, AWS IoT, Microsoft Azure, and Google Cloud. Applications: Secure and connected smart home that improves everyday living with automation, remote control, and more. Space-limited and battery-powered wearables, thanks to their small size and low power consumption Wireless IoT scenarios enable speedy, reliable data delivery. Seeed Studio XIAO ESP32-C6 Development Board Pinout Diagram
